This Concept Map, created with IHMC CmapTools, has information related to: Technology CMAP, Ian Flor My Techonogy CMAP about Apple Ipod, Apple Ipod seven primary components Microprocessor - PortalPlayer PP5021C with dual ARM7TDMI cores, Display - 2.5-inch TFT LCD allows The users to view videos or a view of menus and folders as they use the Click-Wheel, The users to view videos or a view of menus and folders as they use the Click-Wheel view of clickwheel, Apple Ipod seven primary components Audio chip - Wolfson Microelectronics WM8758 codec, Video chip - Broadcom BCM2722 allows Videos and images to be played back upon request, Apple Ipod seven primary components Battery - rechargeable lithium-ion (700 mAh, 3.7V), Apple Ipod seven primary components Video chip - Broadcom BCM2722, Audio signal to audio codec for output thru the headphone/ speaker jack view of microprocessor, Apple Ipod seven primary components Hard Drive I.E. 2, 20, 30gigs, Audio chip - Wolfson Microelectronics WM8758 codec works with the Microprocessor to create audio output, Battery - rechargeable lithium-ion (700 mAh, 3.7V) provides energy source for your personal ipod, Apple Ipod seven primary components Display - 2.5-inch TFT LCD, Microprocessor - PortalPlayer PP5021C with dual ARM7TDMI cores sends Audio signal to audio codec for output thru the headphone/ speaker jack, Click Wheel - navigation via touch-sensitive wheel and mechanical buttons allows The user to navigate all the menus and folders that the IPOD contains, Hard Drive I.E. 2, 20, 30gigs stores MP3 And Video files for playback, Apple Ipod seven primary components Click Wheel - navigation via touch-sensitive wheel and mechanical buttons, Ian Flor lab 10 Technology CMAP, ???? Retrieved From http://electronics.howstuffworks.com/ipod3.htm on April 26th 2006, images and information Retrieved From http://electronics.howstuffworks.com/ipod3.htm on April 26th 2006
